January 9, 2021 at 2:31 pm #227303
dave-bernard
Participant
US Member
those filters have a thread on the bottom that screw into a bridge in the fitting. very thin . it looks like the threads have broken off in the first pics.
January 10, 2021 at 5:25 pm #227364
Boonie
Participant
Canada Member
Need a part # for a water pump impeller for this Kd4?
January 10, 2021 at 8:24 pm #227382
Buccaneer
Participant
US Member
This is what I have in my notes…….

18-3072 Sierra impeller for Mercury KD4

Overall Diameter ： 48mm 1.89
Shaft Size Diameter ： 11mm .433
Depth ：13.5mm .531
Blade ：6

Prepare to be boarded!
January 10, 2021 at 8:32 pm #227383
Buccaneer
Participant
US Member
In looking at my photos on my KD4, it appears I used parts from two different KD’s, one had a wobbler pump,
but I ended up using the Sierra impeller somehow!
Also looks like I make my own impeller drive bushing last winter. Don’t believe I ever got around to running
it to see if it worked.
Other’s have done the retrofit “different than I, so hopefully someone will say how.

Prepare to be boarded!
January 10, 2021 at 8:36 pm #227386
kirkp
Participant
The part number for the vane impeller is M-50-137. Couldn’t find where you have said what your serial number is. According to the info I have, depending on the number you could have a oscillator style impeller. On the first page of your post fifty2One posted pictures with all the part numbers you’ll need.

Kirk
January 11, 2021 at 8:21 pm #227496
Boonie
Participant
Canada Member
Recommended place to find decals for this motor?
January 11, 2021 at 10:02 pm #227503
Buccaneer
Participant
US Member
https://discontinueddecals.com/store/c/34-Mercury-Decals.aspx

is where I got mine.

Prepare to be boarded!
January 12, 2021 at 2:54 pm #227558
fifty20ne
Participant
US MEMBER PAY BY CHECK
I get all mine from Tom Thuerwachter he has many parts for the old “K” series MERCURY’s
January 12, 2021 at 5:16 pm #227565
Buccaneer
Participant
US Member
Winnebagolandchapterland.com takes me to some Chinese site advertising
casino’s, and perhaps more!

Prepare to be boarded!
January 12, 2021 at 6:48 pm #227569
Boonie
Participant
Canada Member
Thanks Guys.
Picked up a new to me motor today. 1956 Johnson Javalin, RJE-18. Good compression and spark on both cylinders. Price was right. Free! Electric start but starter missing. 30 hp. Hard to pull with a rope.
